HPE FlexNetwork 5140 8G 2SFP 2GT Combo EI Switch R8J42A RENEW

Name: HPE FlexNetwork 5140 8G 2SFP 2GT Combo EI Switch R8J42A RENEW
SKU: 713975
Price: 10728 CZK
Availability: InStock

zdarma

-NaN%

HPE FlexNetwork 5140 8G 2SFP 2GT Combo EI Switch R8J42A RENEW

Kód: 713975

EAN: 713975

Záruka: 99 Doživotní

Do oblíbených Porovnání Dotaz prodejci Hlídání

Popis a parametry

Diskuse

HPE FlexNetwork 5140 8G 2SFP 2GT Combo EI Switch R8J42A RENEW

Gigabitový ethernetový přístupový přepínač se statickým směrováním na 3. vrstvě, RIP, vysokou hustotou 10GbE uplinků a modely POE+ pro hlas, video a bezdrátové připojení.
Podporuje technologii IRF, která umožňuje agregaci zařízení plug-and-play a agregaci linek mezi více zařízeními, čímž zvyšuje redundanci sítě a využití zdrojů.
Obsahuje vestavěné funkce pro správu sítě pomocí Smart Management Center (SmartMC).
Zahrnuje energeticky úsporné ekologické konstrukční funkce, jako je automatické přepínání nečinných portů do energeticky úsporného režimu a vypínání nepoužívaných portů.

Klíčové vlastnosti

Škálovatelnost a vysoká dostupnost
Komplexní řízení zabezpečení
Zjednodušená správa
Zvýšená kvalita služeb

Technické parametry
Porty a sloty

(8) RJ-45 autosensing 10/100/1000 ports
(2) SFP fixed 1000/10000 SFP ports
(2) RJ-45 1/10GBASE-T ports

Spotřeba

15 W (maximum)

Rozměry

4.36 x 10.47 x 16 cm

Hmotnost

1.5 kg

Odkaz na stránku výrobce: https://buy.hpe.com/fi/en/networking/switches/fixed-port-l3-managed-ethernet-switches/5100-switch-products/hpe-flexnetwork-5140-ei-switch-series/hpe-flexnetwork-5140-8g-2sfp-2gt-combo-ei-switch/p/R8J42A

Environment	Operating temperature		23°F to 113°F (-5°C to 45°C)
	Operating relative humidity		10% to 90%, noncondensing
	Non-operating/Storage temperature		-40°F to 158°F (-40°C to 70°C)
	Non-operating/Storage relative humidity		5% to 95%, noncondensing
	Acoustic		Low-speed fan: 43.5 dB, High-speed fan: 52.8 dB; ISO 7779
Electrical characteristics	Frequency		50/60 Hz
	Maximum heat dissipation		160/1671 BTU/hr (168.8/1762.91 kJ/hr), for AC power. For DC power min heat dissipation is 147 BTU/hr and 3037 BTU/hr max.
	Voltage		100 - 240 VAC -54 to -57 VDC
	Current		10 A
	Maximum power rating		478 W
	Idle power		47 W
	PoE power		370 W PoE+
	Notes:		- Idle power is the actual power consumption of the device with no ports connected. Maximum power rating and maximum heat dissipation are the worst-case theoretical maximum numbers provided for planning the infrastructure with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all modules populated. PoE Power is the power supplied by the internal power supply. When supplemented with the use of an HPE RPS1600 Redundant Power System, up to 740 W of PoE+ can be supplied. - Max current rating for DC power is 25A. AC Input power is 47W typical, and 490W max(including 370W PoE+ consumption. DC Input voltage range is -54 to -57VDC. Total DC input power is 43W typical and 890W with 800W PoE+ Power consumption. DC Input voltage range is -54VDC to -57VDC. DC Input Source is the HPE RPS1600.
Safety	UL 60950-1; EN 60825-1 Safety of Laser Products-Part 1; EN 60825-2 Safety of Laser Products-Part 2; IEC 60950-1; IEC 62368-1; CAN/CSA-C22.2 No. 60950-1; EN 62368-1/A11; FDA 21 CFR Subchapter J; ROHS Compliance
Emissions	FCC Part 15 Subpart B CLASS A; ICES-003 CLASS A; VCCI-CISPR 32 CLASS A; EN 55032 CLASS; AS/NZS CISPR32 CLASS A; CISPR 24; EN 55024; EN 61000-3-2; EN 61000-3-3; ETSI EN 300 386; GB/T 9254; YD/T 993
Immunity	Generic		EN 55024
	ESD		EN300 386
Management	IMC - Intelligent Management Center; SmartMC; command-line interface; Web browser; SNMP Manager
Services	Refer to the Hewlett Packard Enterprise website at http://www.hpe.com/networking/services for details on the service-level descriptions and product numbers. For details about services and response times in your area, please contact your local Hewlett Packard Enterprise sales office.

HPE FlexNetwork 5140 24G PoE+ 2SFP+ 2XGT (370W) EI Switch (JL823A )
I/O ports and slots	24 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: Ports 1-24 support 10BASE-T/100BASE-TX, 1000BASE-T (full only)
	2 SFP+ fixed 1000/10000 SFP+ ports
	2X1/2.5/5/10G BASE-T ports
Additional ports and slots	1 RJ-45 serial console port
Physical characteristics	Dimensions			17.32(w) x 12.6(d) x 1.72(h) in (44 x 32 x 4.36 cm) (1U height)
	Weight			9.92 lb (4.5 kg)
Memory and processor	512 MB SDRAM, 256 MB flash
Mounting and enclosure	Mounts in an EIA standard 19-inch telco rack or equipment cabinet (hardware included)
Performance	IPv6 Ready Certified
	1000 Mb Latency			< 5 µs
	10 Gbps Latency			< 3 µs
	Throughput			95 Mpps
	Routing/Switching capacity			128 Gbps
	Routing table size			512 entries (IPv4), 256 entries (IPv6)
	MAC address table size			16384 entries
Environment	Operating temperature			23°F to 122°F (-5°C to 50°C)
	Operating relative humidity			10% to 90%, noncondensing
	Non-operating/Storage temperature			-40°F to 158°F (-40°C to 70°C)
	Non-operating/Storage relative humidity			5% to 95%, noncondensing
	Acoustic			Low-speed fan: 44.4 dB, High-speed fan: 52.8 dB; ISO 7779
Electrical characteristics	Frequency			50/60 Hz
	Maximum heat dissipation			83.6/1433 BTU/hr (88.2/1511.9 kJ/hr)
	Voltage			100 - 240 VAC
	Current			10 A
	Maximum power rating			420 W
	Idle power			24.5 W
	PoE power			370 W PoE+
	Notes:			Maximum power rating and maximum heat dissipation are the worst-case theoretical maximum numbers provided for planning the infrastructure with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all modules populated. PoE Power is the power supplied by the internal power supply. When supplemented with the use of an HPE RPS1600 Redundant Power System, up to 740 W of PoE+ can be supplied.
Safety		UL 60950-1; EN 60825-1 Safety of Laser Products-Part 1; EN 60825-2 Safety of Laser Products-Part 2; IEC 60950-1; IEC 62368-1; CAN/CSA-C22.2 No. 60950-1; EN 62368-1/A11; FDA 21 CFR Subchapter J; ROHS Compliance
Emissions		FCC Part 15 Subpart CLASS A; ICES-003 CLASS A; VCCI-CISPR 32 CLASS A; EN 55032 CLASS; AS/NZS CISPR32 CLASS A; CISPR 24; EN 55024; EN 61000-3-2; EN 61000-3-3; ETSI EN 300 386; GB/T 9254; YD/T 993
Immunity		Generic		EN 55024
		ESD		EN300 386
Management		IMC - Intelligent Management Center; SmartMC; command-line interface; Web browser; SNMP Manager.
Services		Refer to the Hewlett Packard Enterprise website at http://www.hpe.com/networking/services for details on the service-level descriptions and product numbers. For details about services and response times in your area, please contact your local Hewlett Packard Enterprise sales office.
HPE FlexNetwork 5140 48G PoE+ 2SFP+ 2XGT (370W) EI Switch (JL825A )
I/O ports and slots	48 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only
	2 SFP+ fixed 1000/10000 SFP+ ports
	2X1/2.5/5/10G BASE-T ports
Additional ports and slots	1 RJ-45 serial console port
Physical characteristics	Dimensions			17.32(w) x 12.6(d) x 1.72(h) in (44 x 32 x 4.36 cm) (1U height)
	Weight			13.23 lb (6 kg)
Memory and processor	512 MB SDRAM, 256 MB flash
Mounting and enclosure	Mounts in an EIA standard 19-inch telco rack or equipment cabinet (hardware included)
Performance	IPv6 Ready Certified
	1000 Mb Latency			< 5 µs
	10 Gbps Latency			< 3 µs
	Throughput			131 Mpps
	Routing/Switching capacity			176 Gbps
	Routing table size			512 entries (IPv4), 256 entries (IPv6)
	MAC address table size			16384 entries
Environment	Operating temperature			23°F to 122°F (-5°C to 50°C)
	Operating relative humidity			10% to 90%, noncondensing
	Non-operating/Storage temperature			-40°F to 158°F (-40°C to 70°C)
	Non-operating/Storage relative humidity			5% to 95%, noncondensing
	Acoustic			Low-speed fan: 43.5 dB, High-speed fan: 52.8 dB; ISO 7779
Electrical characteristics	Frequency			50/60 Hz
	Maximum heat dissipation			117.7/1467 BTU/hr (124/1547.77 kJ/hr)
	Voltage			100 - 240 VAC
	Current			10 A
	Maximum power rating			430 W
	Idle power			34.5 W
	PoE power			370 W PoE+
	Notes:			Maximum power rating and maximum heat dissipation are the worst-case theoretical maximum numbers provided for planning the infrastructure with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all modules populated. PoE Power is the power supplied by the internal power supply. When supplemented with the use of an HPE RPS1600 Redundant Power System, up to 740 W of PoE+ can be supplied.
Safety		UL 60950-1; EN 60825-1 Safety of Laser Products-Part 1; EN 60825-2 Safety of Laser Products-Part 2; IEC 60950-1; IEC 62368-1; CAN/CSA-C22.2 No. 60950-1; EN 62368-1/A11; FDA 21 CFR Subchapter J; ROHS Compliance
Emissions		FCC Part 15 Subpart CLASS A; ICES-003 CLASS A; VCCI-CISPR 32 CLASS A; EN 55032 CLASS; AS/NZS CISPR32 CLASS A; CISPR 24; EN 55024; EN 61000-3-2; EN 61000-3-3; ETSI EN 300 386; GB/T 9254; YD/T 993
Immunity		Generic		EN 55024
		ESD		EN300 386
Management		IMC - Intelligent Management Center; SmartMC; command-line interface; Web browser; SNMP Manager.
Services		Refer to the Hewlett Packard Enterprise website at http://www.hpe.com/networking/services for details on the service-level descriptions and product numbers. For details about services and response times in your area, please contact your local Hewlett Packard Enterprise sales office.
HPE FlexNetwork 5140 8G 2SFP 2GT Combo EI Switch (R8J42A )
I/O ports and slots	8 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: Ports 1-8 support 10BASE-T/100BASE-TX, 1000BASE-T (full only)
	2 SFP fixed 1GbE ports
	2 GT ports
Additional ports and slots	1 RJ-45 serial console port
Physical characteristics	Dimensions			10.47(w) x 6.3(d) x 1.72(h) in (26.6 x 16 x 4.36 cm) (1U height)
	Weight			3.3 lb (1.5 kg)
Memory and processor	512 MB SDRAM, 256 MB flash
Mounting and enclosure	Mounts in an EIA standard 19-inch telco rack or equipment cabinet (hardware included)
Performance	IPv6 Ready Certified
	1000 Mb Latency			< 5 µs
	10 Gbps Latency			< 3 µs
	Throughput			18 Mpps
	Routing/Switching capacity			24 Gbps
	Routing table size			512 entries (IPv4), 256 entries (IPv6)
	MAC address table size			16384 entries
Environment	Operating temperature			23°F to 122°F (-5°C to 50°C)
	Operating relative humidity			10% to 90%, noncondensing
	Non-operating/Storage temperature			-40°F to 158°F (-40°C to 70°C)
	Non-operating/Storage relative humidity			5% to 95%, noncondensing
	Acoustic			High-speed fan: 36.8 dB; ISO 7779
Electrical characteristics	Frequency			50/60 Hz
	Maximum heat dissipation			27.3/51.2 BTU/hr (28.8/54 kJ/hr)
	Voltage			100 - 240 VAC
	Current			10 A
	Maximum power rating			15 W
	Idle power			8 W
	Notes:			Maximum power rating and maximum heat dissipation are the worst-case theoretical maximum numbers provided for planning the infrastructure with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all modules populated. PoE Power is the power supplied by the internal power supply. When supplemented with the use of an HPE RPS1600 Redundant Power System, up to 740 W of PoE+ can be supplied.
Safety		UL 60950-1; EN 60825-1 Safety of Laser Products-Part 1; EN 60825-2 Safety of Laser Products-Part 2; IEC 60950-1; IEC 62368-1; CAN/CSA-C22.2 No. 60950-1; EN 62368-1/A11; FDA 21 CFR Subchapter J; ROHS Compliance
Emissions		FCC Part 15 Subpart CLASS A; ICES-003 CLASS A; VCCI-CISPR 32 CLASS A; EN 55032 CLASS; AS/NZS CISPR32 CLASS A; CISPR 24; EN 55024; EN 61000-3-2; EN 61000-3-3; ETSI EN 300 386; GB/T 9254; YD/T 993
Immunity		Generic		EN 55024
		ESD		EN300 386
Management		IMC - Intelligent Management Center; SmartMC; command-line interface; Web browser; SNMP Manager.
Services		Refer to the Hewlett Packard Enterprise website at http://www.hpe.com/networking/services for details on the service-level descriptions and product numbers. For details about services and response times in your area, please contact your local Hewlett Packard Enterprise sales office.
