Socket type

AMD Socket 754, 939, AM2, AM2+, AM3, AM3+, FM1, FM2

Cooler dimension

80 x 80 x 30.8mm

Heatsink material

Aluminum

Weight

224g

Installation

Cam-lever clip

Fan dimensions

80 x 80 x 10mm

Fan speed

600 - 3000 RPM (PWM controlled)

Max airflow

26.53CFM (45.0 mł/h)

Max air pressure

1.81mm H2O

Max noise level

27.09dB(A)

Current rating

0.15A

Voltage rating

12V DC

Bearing type

EBR

Fan life expectancy

40,000 hours

Fan connector

4pin PWM

Product code

AK-CC1101EP02
